CYT 41 Diesel Engine Underground Mining Drilling Machine Bench Crest Drilling Machine

1. Applicable Scenarios

CYT41 hydraulic mining drill (model and name required by safety standards) is a fully mechanized drilling and blasting machine with functions such as drilling and installing explosives. The rock drill uses a pneumatic rock drill, which is more cost-effective. It is suitable for secondary crushing operations in underground mines such as metal mines, non-metal mines, water conservancy and hydropower, etc. that do not require explosion-proof, such as eyebrow lines, tunnels, and stopes. It can achieve bench crest dredging and crushing of large pieces of ore.

2. Technical features

. Multi-function: drilling, placing explosives, etc.;

. Flexibility: modular design, compact and reasonable layout, articulated steering, flexible walking and turning;

. Powerful power: full diesel power, torque converter four-wheel drive engineering chassis;

. Safety: hydraulic wet dual brake system, driving oil brake, parking closed spring brake;

. Equipped with prefabricated PVC pipe explosive roll magazine, a single entry can complete the installation of 1 roll;

. Internal blasting effect far exceeds the currently commonly used surface blasting effect;

. Accuracy: drill arm support mechanism, rock drill and roll installation push rod rotation switch;

. Remote control system (optional), can realize drilling, charging, switching workstations and other operations through remote control, safe and reliable;
